McIntosh MHT200

25
SETUP
The following listings indicate the factory default settings.
Refer to the listed page number for instructions on how to
change a default setting.
Default Settings
Speaker Size:
Speaker Type Size or ON/OFF Refer to Page
Front ........................ Small ........................... 27
Center ...................... Small ........................... 27
Surround.................. Small ........................... 27
Back ........................ 1 Small ........................ 27
Subwoofer ............... Yes .............................. 27
Speaker Level:
Speaker Location Initial Level Refer to Page
Left Front ...................0dB ........................... 28
Center ......................... 0dB ........................... 28
Right Front .................0dB ........................... 28
Right Surround ...........0dB ........................... 28
Right Back .................None ......................... 28
Left Back ....................0dB ........................... 28
Left Surround .............0dB ........................... 28
Subwoofer ..................0dB ........................... 28
Speaker Time Delay:
Speaker Location Distance Refer to Page
Left Front .............. 6ft ................................. 31
Center .................... 5ft ................................. 31
Right Front ............ 6ft ................................. 31
Right Surround ...... 3ft ................................. 31
Right Back ............ None ............................. 31
Left Back ............... 0ft ................................. 31
Left Surround ........ 3ft ................................. 31
Subwoofer ............. 0ft ................................. 31
Subwoofer Settings:
Setting Initial Setting Refer to Page
MC Bass .....................Off ............................ 33
Sub Crossover ............80Hz ......................... 33
Dolby LFE
1
Level ......0dB ........................... 33
Sub Filter ....................On ............................. 33
1
DD (Dolby Digital) LFE (Low Frequency Effect) Sound
Information is usually assigned to the Subwoofer Channel. If
the Subwoofer Channel is switched off and the Front
Channel Loudspeakers are set to Large in the Speaker Size
Setup Menu, the LFE Sound Information will be redirected
to the Large Loudspeaker(s).
5. Exit the MAIN SYSTEM SETUP Menu by pressing
the Up or Down directional push-buttons followed
by the SELECT Push-button.
6. If adjustments have been performed, the Adjustment
Acceptance Menu will appear on the Monitor/ TV
screen asking if you want to save the adjustments in
memory. Use the Up or Down directional push-
buttons to select YES to save, or NO to not save, then
press the SELECT Push-button to exit the Setup Mode
and return to normal operation. Refer to figure 13.
Figure 12
MAIN SYSTEM SETUP
1. SPEAKER SETUP
2. SOURCE SETTINGS
3. VIDEO POWER CONTROL
4. TUNER PRESETS
5. MODE SETUP
6. SYSTEM SETTINGS
EXIT
Figure 13
DO YOU WANT TO SAVE THEM?
0. NO
1. YES
