56
Frequency Response
Left, Center, Right,
Left Surround,
Right Surround,
Left Back, Right Back:
±0.5dB from 20Hz-20,000Hz
Subwoofer
1
:
±0.5dB from 20Hz-140Hz
Rated Output
2V for all channels
Input Impedance
22K ohms
Output Impedance
Less than 560 ohms for all channels
Maximum Output Voltage
8V
Total Harmonic Distortion
0.05% for all channels
Sensitivity
Analog Input: 100mV IHF
Dolby Level 200mV Input
External Input 200mV for 2.0V output
Signal To Noise Ratio
Greater than 90dB A weighted
Maximum Input Signal
Analog Input: 6Vrms
Tone Controls
±12dB from the flat setting
1
If any of the Channels have the Loudspeaker Setting of
Small, the subwoofer has an electronic low pass filter
with a 24dB per Octave rolloff in all modes except exter-
nal.
Preamplifier and Processor Specifications
Preamplifier and Processor Specifications
