McIntosh MHT200

64
How to Operate the Tuner
The McIntosh MHT200 TM1 AM/FM Tuner Module in-
corporates an advanced design AM/FM Tuner with many
desirable performance features to enhance your enjoyment
of radio broadcasts. There are several methods of tuning to
an AM/FM Broadcast Station by using the Front Panel
Trim/Tune Function and the Remote Control.
Front Panel Tuning Functions
1. Select TUNER with the Front Panel INPUT Selector
Switch. Refer to figure 86.
2. Rotate the TRIM SELECT Control to the TUNE Posi-
tion and press the TRIM/TUNE Up or Down
Push-button on the Front Panel until the desired AM or
FM Broadcast Station Preset is selected.
Remote Control Tuning Functions
3. Select TUNER with the Remote Control TUNER Push-
button. Refer to figures 86 and 87.
4. Select the desired Broadcast Band by pressing either
the FM or AM Push-button.
Note: The first time the FM or AM Push-button is pressed
the Front Panel Alphanumeric will display Signal
Strength, Stereo/Mono (for FM Broadcasts only)
and the default Preset Name or the Custom Entered
How to Operate the Tuner
Figure 86
Figure 84
Figure 87
Preset Name. Refer to
figure 84 The second
time the FM or AM
Push-button is pressed
the Front Panel
Alphanumeric will
display the Signal
Strength, Stereo/Mono
(for FM Broadcasts
only), the frequency of
the station and the
Preset Number if the
station has been
stored into memory.
Refer to figure 85.
5. Press and quickly release the
CHANNEL Up or
Down Push-button on the
Remote Control to find the
next available station. Press
and hold to move continu-
ously up or down the broad-
cast band. When a station is
selected, the Front Panel Al-
phanumeric Display will in-
dicate (from left to right)
Station Signal Strength from
1 to 9, a dot if the Broadcast
is Stereo, the AM/FM Sta-
tion Frequency, AM or FM
Broadcast Band and a Preset
Number (if that station has
been assigned a Preset).
Figure 85
