McIntosh MHT200

35
SETUP, con’t
Figure 27
MENU: SUBWOOFER SETTINGS
1. MC BASS MODE Off
2. SUB CROSSOVER 80 Hz
3. DOLBY LFE LEVEL 0dB
4. SUB FILTER On
EXIT
10. Continue next to the SUB FILTER Setting. If you do
not wish to perform SUB FILTER Adjustments at this
time, proceed to the next step.
11. Select EXIT from the SPEAKER SETUP Menu. The
MAIN SETUP Menu will reappear on the Monitor/TV
screen and select EXIT from the Menu. If you are sat-
isfied with the changes that you may have made, select
YES to save those changes or NO not to save them.
The MHT200 will then return to normal operation. Re-
fer to figure 13 on page 25.
Subwoofer Filter
The Subwoofer Filter works in conjunction with the se-
lected Sub Crossover point and the filter allows for rolling
off frequencies above the crossover setting. This filter only
affects the subwoofer output. Refer to figure 28.
Note: This feature is to be used with a powered subwoofer that
has a built-in electronic crossover.
12. Using the Up or Down directional push-buttons
select SUB FILTER from the On-Screen Menu, fol-
lowed by pressing the Left or Right directional
push-buttons to switch off the filter. Select EXIT on the
menu and the SPEAKER SETUP Menu will reappear
on the Monitor/TV screen.
13. Continue to the next SOURCE SETTINGS, if you do
not wish to perform the remaining SOURCE SET-
TINGS Adjustments at this time, then proceed to the
next step.
Adjustment Default Setting New Setting
MC Bass Mode Off
Sub Crossover 80Hz
Dolby LFE Level 0dB
Sub Filter On
Subwoofer Settings
Figure 28
MENU: SUBWOOFER SETTINGS
1. MC BASS MODE Off
2. SUB CROSSOVER 80 Hz
3. DOLBY LFE LEVEL 0dB
4. SUB FILTER Off
EXIT
14. Select EXIT from the SPEAKER SETUP Menu. The
MAIN SETUP Menu will reappear on the Monitor/TV
screen and select EXIT from the Menu. If you are sat-
isfied with the changes that you may have made, select
YES to save those changes or NO not to save them.
The MHT200 will then return to normal operation. Re-
fer to figure 13 on page 25.
