51
2. Press and release the LEVEL Up Push-button until
the +10 appears to the right of BASS TRIM on the
Front Panel Alphanumeric Display. This is an example
of increasing the Bass response by +10dB.
3. Press and release the TRIM Push-button until TREB
TRIM appears on the Front Panel Alphanumeric Dis-
play. Refer to figure 57.
4. Press and release the LEVEL Up Push-button until
the +11 appears to the right of TREB on the Front
Panel Alphanumeric Display. This is an example of in-
creasing the Treble response by +11dB.
Display Brightness
The MHT200 Trim feature allows adjustments to the
brightness of the Front Panel Alphanumeric Display to the
desired intensity. The Display Trim brightness range ex-
tends from Off to a maximum of 10.
Note: You may find it easiest to make Display adjustments
with the Front Panel Controls.
How to Operate the MHT200, con’t
Figure 59
1. Press and release the TRIM Push-button on the Remote
Control, or rotate the TRIM SELECT Control, until
DISPLAY appears on the Front Panel Alphanumeric
Display. A number to the right of the display indicates
the current brightness level. Refer to figure 58.
2. Press a LEVEL Up or Down Push-button on the
Remote Control, or rotate the TRIM LEVEL Control,
until you reach the desired display brightness.
Figure 56
Figure 57
Figure 58
