62
locations other than the US where stations change in
50Hz steps. AM Broadcast Band Indications are in
kilohertz and change frequency in 10kHz steps.
Label
6. Using Up or Down directional push-buttons select
LABEL followed by pressing the SELECT Push-but-
ton. The On-Screen Menu will now change, allowing
the current Label Name to be altered. Refer to figure
81.
7. The On-Screen Display will show an arrow under-
neath the left most character of the current LABEL
Name. Press the Up or Down directional push-
buttons to select the desired character from the avail-
able characters that include the alphabet, numbers and
symbols.
8. To change the next character press the Right direc-
tional push-button to move the arrow to change the
next character. Press the Up or Down directional
push-buttons again to select the desired character.
9. Repeat step 6 until the desired Preset Label Name is
complete. Refer to figure 82.
Note: The Preset Label Name can be up to seven
characters long.
10. After the last character has been entered press the
Left or Right directional push-buttons (or press the
SELECT Push-button) until the TUNER PRESET
Menu displays an arrow in front of PRESET AS-
SIGNED.
Preset Assigned
11. Using Up or Down directional push-buttons select
PRESET ASSIGNED from the On-Screen Menu, fol-
lowed by pressing the Left or Right directional
push-buttons to select Yes or No. If No is selected the
MHT200 will skip that Preset, even though it has been
entered. Refer to figure 83. Select EXIT on the menu
and the MAIN SYSTEM SETUP Menu will reappear
on the Monitor/TV screen.
12. Continue next to the MODE SETUP on page 42 or if
you do not wish to perform MODE SETUP Adjust-
ments at this time, proceed to the next step.
13. Select EXIT from the MAIN SYSTEM SETUP Menu.
If you are satisfied with the changes that you may have
made, select YES to save those changes or NO not to
save them. The MHT200 will then return to normal op-
eration. Refer to figure 13 on page 25.
Figure 80
MENU: TUNER PRESETS
1. PRESET FM1
2. TUNING MODE Auto
3. FREQUENCY 91.50 MHz
4. LABEL PRESET 1
5. PRESET ASSIGNED Yes
EXIT
Figure 81
MENU: TUNER PRESETS
1. PRESET FM1
2. TUNING MODE Auto
3. FREQUENCY 91.50 MHz
4. LABEL PRESET 1
EXIT
