McQuay TSC User Manual

OM Centrif Micro ΙΙ-5 45
Set Screens
SET UNIT SPs (1)
Enable =
Mode =
Source =
SET COMP #1
SPs (1)
Demand Limit=
Minimum Amps = %
Maximum Amps= %
SET COMP#2 SPs (1)
Demand Limit=
Minimum Amps= %
Maximum Amps= %
SET ALARM SPs (1)
LowEv PrHold =
Low Ev Pr Unld =
Low Ev Pr Stop =
SET TOWER SPs (1)
TowerControl-Temp =
TowerStages =
StageUp/Dn = xxx/xxx
SET UNIT SPs (2)
Available Modes
Select w/Unit Off
SET COMP SPs (2)
Stag
eMode =
StageSequence# =
Max Compr ON =
SET COMP#2 SPs (2)
StageMode =
StageSequence# =
Max Compr ON =
SET ALARM SPs (2)
High Cond Pr =
HiDiscT-Load =
HiDiscT-Stop =
SET TOWER SPs (2)
StageOn(Temp) ° F
#1 #2 #3 #4
xxx xxx xxx xxx
SET UNIT SPs (3)
Cool LWT =
Ice LWT =
Heat LWT =
SET COMP SPs (3)
StageDeltaT =
Stop-Srart = min
Start-Start = min
SET COMP#2 S
Ps (3)
StageDeltaT =
Stop-Srart = min
Start-Start = min
SET ALARM SPs (3)
High HiOilFeedTemp =
LowOilDeltaT =
LowNetOilPr =
SET TOWER SPs (3)
StageDiff =
StageUp =
StageDown =
SET UNIT SPs (4)
Leaving Water Temp.
StartDelta =
StopDelta =
SET COMP SPs (4)
Full Load = sec
SET COMP#2 SPs (4)
Full Load = sec
SET ALARM SPs (4)
Surge Slp Str = XX ° F
Surge Temp Run=XX ° F
MtrCurrThrshld =
SET TOWER SPs (4)
Valve/VFDControl =
ValveSp/VFDStage
ValveType =
SET UNIT SPs (5)
Rest Type =
Max Reset DT =
Strt Reset DT =
SET COMP SPs (5)
OilNoStrtDiff=
Abs Capacity = T
HotGasBypass = %
SET COMP#2 SPs (5)
OilNoStrtDiff=
Abs Capacity = T
HotGasBypass = %
SET TOWER SPs (5)
Valve SP =
Valve DB =
SET UNIT SPs (6)
Soft Load =
BeginAmpLimit =
SoftLoadRamp =
SET COMP SPs (6)
Unload Timer = sec
PreLubeTmrs= sec
PostLub Tmrs= sec
SET COMP#2 SPs (6)
Unload Timer = sec
PreLubeTmrs= sec
PostLub Tmrs= sec
SET TOWER SPs (6)
Valve Start Position
Min = xxx%@xxx ° F
Max = xxx%@xxx ° F
SET UNIT SPs (7)
Max/Min LWT Rates
Max = /min
Min = /min
SET COMP SPs (7)
VaneMode =
Vanes =
%RLA= %
SET COMP#2 SPs (7)
VaneMode =
Vanes =
%RLA= %
SET TOWER SPs (7)
Valve Control Range
Min = %
Max = %
SET UNIT SPs (8)
EvapRecTmr = min
EvapPump =
CondPump =
SET COMP SPs (8)
VFD Mode =
VFD = %
%RLA = %
SET COMP#2 SPs (8)
VFD Mode =
VFD = %
%RLA = %
SET TOWER SPs (8)
PD Control Loop
Error Gain = %
Slope Gain = %
SET UNIT SPs (9)
Templifier Src Water
No start = 70 ° F
Delta Reset=055 ° F
SET COMP SPs (9)
Protocol = MODBUS
Id #=001 Units=IP
Baud Rate=19200
SET COMP SPs (9)
Protocol = MODBUS
Id #=001 Units=IP
Baud Rate=19200
SET UNIT SPs (10)
VFD =
Min Speed = %
Spd/Lift = %/
SET COMP SPs (10)
Refrig Sat Pressure
Evap Offset = 00.0 psi
Cond Ofset = 00.0 psi
SET COMP SPs (10)
Refrig Sat Pressure
Evap Offset = 00.0 psi
Cond Ofset = 00.0 psi
SET UNIT SPs (11)
Max Water Flow Rates
Evap WF = XXXXX GPM
Cond WF = XXXXX GPM
SET COMP SPs (11)
ELWT Offset = 0.0 ° F
Oil Sump OS = 00.0 psi
Oil Feed OS = 00.0 psi
SET COMP SPs (11)
ELWT Offset = 0.0 ° F
Oil Sump OS = 00.0 psi
Oil Feed OS = 00.0 psi
SET ALARM SPs (5)
EvapFreeze =
CondFreeze =
SET UNIT SPs (12
Standard Time
17/March/2005
12:20 THU
SET UNIT SPs (13)
Display Format
Units =
F/psi (IP)
Lang = English
SET UNIT SPs (14)
Protocol = MODBUS
Id #=001 Units=IP
Baud Rate=19200
SET UNIT SPs (15)
Ex-Valve Gain = 100
Offset(Slope) = 271
Pr Ctrl Dout = 10 ° F
