mectron COMPACT PIEZO LED - Layout G; Layout H

22
COMPACT PIEZO LED
4.3.8.7 LayoutG
Thepowersupply (24V~50/60 Hz±10%or 32V ±10%) andconsentare providedbythe
pedal.
The power is regulated by a variable voltage between 0 and 5 V (see Figure11apagina22).
Power supply
24 Vac ± 10% 50/60 Hz
or 32 Vdc ± 10%
Minimum 40W
9 16
8 7 6 5 4 3 2 1
Fuse holder, fuse and pedal
are not included in the
Mectron supply
Pedal
T 2 A
Fuse
Yellow
Black
Red
White
White
Scaler handpiece cord
82 KΩ 1/8 W 1%
resistance
Brown
-
+
Power adjustment
variable voltage
-
+
0-5 V 1mA
Ferrite*
Grey
Purple
12
Figure11 – LayoutG
4.3.8.8 LayoutH
The power supply (32 V ±10%)isprovidedbycontactwiththeinstrumenttrayandnegative
consent is provided by the pedal. The power is regulated by a variable voltage between 0 and
10 V (see Figure12apagina22).
9 16
8 7 6 5 4 3 2 1
Pedal
T 2 A
Fuse
Black
Red
Scaler handpiece cord
Instrument tray
Power supply
32 Vdc ± 10%
Minimum 40W
White
Black
uelB
Fuse holder, fuse,
pedal and instrument
tray not included in
the Mectron supply
-
+
Power adjustment
variable voltage
-
+
Yellow
10 KΩ 1/8 W 1%
resistance
0-10V 1mA
Ferrite*
Grey
Purple
12
Figure12 – Layout H
