COMPACT PIEZO LED
6.1.3 Guidance and Manufacturer’s Declaration - Electromagnetic
Immunity
6.1.3.1 A.C.InputPowerConnection
compactpiezoLEDisdesignedtooperateintheelectromagneticenvironmentspeciedbelow.
The customer or user of compact piezo LED should always make sure that it is used only in such
an environment.
Phenomenon
BasicEMC
standardortest
method
Immunitytestlevels
Electromagnetic
environment-Guidance
Electrical fast
transients/
bursts
a) l) o)
IEC61000-4-4
±2 kV on contact
100 KHz repetition
frequency
The quality of the power
supply should be that of a
typical commercial or hospital
environment.
Surges
a) b) j) o)
Line-to-Line
IEC61000-4-5 ± 0,5 kV, ± 1 kV
The quality of the power
supply should be that of a
typical commercial or hospital
environment.
Surges
a) b) j)
k) o)
Line-to-
Ground
IEC61000-4-5 ± 0,5 kV, ± 1 kV, ± 2kV
The quality of the power
supply should be that of a
typical commercial or hospital
environment.
Conducted
disturbances
inducebyRF
elds
c) d) o)
IEC61000-4-6
3 V
m)
0,15 MHz - 80 MHz
6V
m)
in ISM bands
between 0,15 MHz and
80 MHz
n)
80%AMat1KHz
e)
PortableandmobileRF
communication devices
should not be used near any
part of the product, including
cables, except when they
respect the recommended
distances, calculated from the
equation applicable at the
frequency of the transmitter.
Voltage dips
f) p) r)
IEC61000-4-11
0%UT;0,5cycle
g)
at 0°, 45°, 90°, 135°,
180°,225°,270°e315°
The quality of the power
supply should be that of a
typical commercial or hospital
environment.
0%UT;1cycleand
70%UT;25/30cycle
h)
Single phase: at 0°
Voltage
interruptions
f) i) o) r)
IEC61000-4-11 0%UT;250/300cycle
h)
The quality of the power
supply should be that of a
typical commercial or hospital
environment.
