PCF Pro User Manual
DOC01851 Page 43 of 74
Automated Wash Cycle
The automated wash cycle consists of the stages Pre-wash, Wash, Rinse, Final Rinse/Disinfection,
Cooling and Drying. Every stage of the cycle is configured by the Program Parameters stored in the
machines memory (see section 3-5-1). These parameters allow the cycle to be customised to select
the fill water type, skip stages, repeat stages, control temperature set points, set stage duration etc.
During a cycle, the remaining time for each stage will be shown on the right hand side of the display,
and the temperature/pump pressure on the left.
Cycle Process
Start Cycle
• Lock Lid The lid is sealed shut to prevent entry during the cycle
Pre-wash
• Fill Fill tank with cold water to the minimum level
• Cycling For a set period alternate between spray arms (45s) and lumen flushing (15s), heating up to 35°C
• Drain Drain until tank is empty, then for a further 20s
Wash
• Fill Fill tank with cold and hot water mix up to the top level
• Dose Detergent is added once the minimum tank level is reached
• Heat Heat water to the set point, circulating through the lumens and spray arms
• Degas Pulse ultrasonics on and off for the degas period, with no recirculation
• Cycling Alternate between ultrasonics (45s) and lumen flushing (15s) for a set period
• Drain Drain until the tank is empty, then for a further 20s
Rinse
• Fill Fill tank with Hot water upto the minimum level
• Cycling For a set period alternate between spray arms (45s) and lumen flushing (15s), heating up to the set point
• Drain Drain until the tank is empty, then for a further 20s
Final Rinse /
Disinfection
• Fill Fill tank with Hot/RO water upto the minimum level
• Heat Heat water to the set point, circulating through the lumens and spray arms
• Cycling For a set period circulate through the lumens and lid spray
• Drain Drain until the tank is empty, then for a further 20s
Cooling
• Fill Add cold or RO water run down the back of the tank up to the bottom level
• Drain Continuously drain the tank throughout
• Repeat Repeat the cooling process until chamber temperature below 60°C
• Drain Drain until the tank is empty, then for a further 20s
Drying
• Soft-shot For a set period compressed air is alternately blown through the irrigation ports and spray arms
Cycle
Complete
• Confirm Acknowledge cycle complete by pressing unload on the display
