PCF Pro User Manual
DOC01851 Page 61 of 74
Ultrasonics
Typical Frequency 38 to 40 kHz dependant on load
Transducers 84 piezo ceramic
Power 3kW
Features
Pulsed Degas
Auto-tune
Frequency Sweep
Reflectasonic Technology
Water Supply
Back Siphonage Protection Integral AB type air gap and weir observing BS EN 1717
Consumption
(approximate)
Per cycle stage:
• Pre-wash 40lts (10.5US gal)
• Wash 250lts (66US gal)
• Rinse 40lts (10.5US gal)
• Disinfection 40lts (10.5US gal)
• Disinfection Condensate 165lts (43.5US gal)
• Cooling 105lts (28US gal)
Total Per supply:
• Cold 288lts (76US gal)
• Hot 247lts (65US gal)
• RO 145lts (38US gal)
Total Cycle 680ltrs (180US gal)
Consumption will vary depending on the cycle selected and the site facilities
Electrical Supply
General
Mains supply voltage fluctuations up to ±10% of the nominal voltage;
Transient over voltages typically present on the mains supply (Overvoltage
Category II).
Pollution Degree 2
MED11180
(380 - 415VAC 50Hz)
Voltage: 380 - 415VAC 3P+N+PE (Three Phase + Neutral + Protective Earth)
Frequency: 50Hz
Power: 22kW
Site Current Capacity: ≥ 30A per phase
Site MCB and Disconnect Switch Current Rating: 40A
Site Wiring Cross-sectional area: 6 mm
2
MED11180
(200 - 230VAC 60Hz)
Voltage: 200 - 230VAC 3P+PE (Three Phase + Protective Earth)
Frequency: 60Hz
Power: 18kW
Site Current Capacity: ≥ 48A per phase
Site MCB and Disconnect Switch Current Ratting: 63A
Site Wiring Cross-sectional area: 10mm
2
