Basic User Manual
Digital Color Doppler Ultrasound System
Set key
Press it to confirm the current operation.
Zoom key
Press it to zoom in or out the image..
Distance key
Press it to activate the distance measurement.
Trace key
Press it to activate the trace measurement.
Ellipse key
Press it to activate the ellipse measurement..
Calc
Press it to activate the measurement menu.
TGC slide pot
Use these 8 TGC slide pots to adjust the gain value of
the specific area on the image.
