FRAX User's Manual
© 2011 Megger Sweden AB
Protective Earth/Ground
symbol and Protective
Earth/Ground connector
Always connect the instrument to station earth/ground using
the separate earth/ground cable. The separate earth/ground
wire should be the first connection made and the last
removed.
Probe
Connector for active probes. Optional and available on order.
Caution, risk of danger
symbol
Refers to follow instructions stated in User's Manual to ensure
safety. See Safety First.
1.3.1.2
Rear Panel
Left-hand side, top down:
Informative text
Serial number
Right-hand side, top
down:
DC input
DC-input, to connect the double insulated AC/DC adapter.
DC symbol. Polarity Symbol.
CE-mark
Megger guarantee that this product complies with relevant
CE directives and corresponding standards.
Calibration date

Megger frax 101 Specifications

General

Brand	Megger
Model	frax 101
Category	Measuring Instruments
Language	English
