79
Appendices
© 2011 Megger Sweden AB
5.5.1.2
Measure Cable connection (black)
Cable strain relief
Coaxial cable from FRAX
(Measure)
Ground braid connected to ground.
Keep the braid straight along the
bushing and ground the braid at
the base of the bushing. Ensure
good connection to ground using
the G-clamp.
