5.5.3 Field Test Box FTB 101
Connect C-clamp
to FTB101
Connect the
Measure cable
Attach the G-clamp
to ground on the
FTB101
Connect the
braid to the
G-clamp
Connect the ground
cable from FRAX
to the G-clamp
Connect C-clamp
to FTB101
Connect the
Generator cable
Connect the
braid to the
G-clamp
