6
■ Assets should not be routinely flash tested. Where flash testing is required, refer to further guidance on Flash testing,
section A7
■ Replacement fuses must be of the correct rating and type. Refer to section 1.8
■ The USB connection marked thus should only be used by approved service personnel; nothing should be connected
to the USB port during testing.
■ Only use a NiMH rechargeable 8.4 V PP3 battery, do not use a non rechargeable type as this could become dangerous if
charged by the instrument.
■ Serviceable fuses should only be replaced with those that are suitably rated
■ In case of an emergency use an easily accessible power point
■ Only use Megger approved accessories with this product
CAT II
Measurement category II: Equipment connected between the electrical outlets and the user’s equipment.
CAT III
Measurement category III: Equipment connected between the distribution panel and the electrical outlets.
CAT IV
Measurement category IV: Equipment connected between the origin of the low-voltage mains supply and the distribution panel.
X.3 Symbols used on the instrument
F Caution: risk of electric shock
G Caution: refer to accompanying notes.
c Equipment complies with relevant EU Directives
Equipment complies with ‘C tick’ requirements
f Fuse
This equipment should be recycled as electronic waste
U HV test lead in unlocked position
L HV test lead in locked position
LR6 AA
NIMH 8.4V
PP3/6R31
Battery type fitted
230 V
X
Do NOT connect to mains supply
