www.megger.comPAT400 Series

15. Care and maintenance

The PAT400 should only be opened or repaired by an approved Megger service centre or by Megger Instruments Limited.

To clean the instrument; disconnect the instrument from the power supply then use a clean cloth dampened with water or isopropyl

alcohol.

To clean the display window only use a lint free cloth. For warranty repairs see appendix E.
