c. M6 lock nut
11. Tighten the hex nut just enough so that the user interface stays in position, yet it can be adjusted
by hand up and down easily.
12. Connect the keyboard harness to the socket in the back of the user interface panel.
13. Turn the machine ON.
14. Repeat the keypad test described in paragraphs 2 through 4 and verify that the user interface is
fully functional. If you have difculty in installation or should the problem still persist after com-
pleting the above procedures, contact Technical Support for assistance.
