LED Cluster Assembly Failures
Condition Solution
Both LED Cluster Assemblies do not illuminate with
the rest of machine having power.
Troubleshoot the wiring connecting the Main PCB
to the LED Cluster assemblies.
One LED Cluster assembly is completely illuminated
but the other one is not.
Verify the harness connection rst. Then replace
the non-functional LED cluster assembly.
Individual LEDs on either LED Cluster Assembly are
burned out or fail to illuminate.
Replace the LED Cluster assembly affected.
