Weekly Maintenance
•
WARNING!! If you currently have a hoop or clamping system on the machine, please remove it.
Failure to fully remove a clamping system can result in damage to the machine.
Needle Drive
1. Color change to Needle 16.
2. Go to “Tools>Maintenance>Head Timing Tab”.
3. Go to “Top Center”
4. Using a small oiler bottle, put twenty-ve drops (25) of sewing machine oil in the oiling change as
shown in the image.
•
Note: You may have to add a few drops and wait before adding more to prevent the channel
from overowing.
5. After adding the oil, wait ten minutes before continuing.
6. In the Head Timing Tab, go to “Head Up”.
Left Upper V-Rail
7. Using a piece of lint-free cloth, wipe clean both the front and back surfaces of the upper v-rail on
the LEFT side of the needlecase.
8. After cleaning the v-rail, use a small oiler bottle to apply a drop of oil each to the front and the
back surfaces of the v-rail. Apply the oil close to the needlecase.
