Operation Manual Menzi Muck A91 Page 57
Control and Display elements
Keyword index
DIGSY Display + control
DIGSY Compact DCE Control (built into the midsection, to the rear, lower right)
CGMT Display (built into the console)
ECU Engine electronics of the John Deere engine
RC4-4/20 electronic maximum load control (GLR)
ICN-V control integrated into chassis
CR2011 auxiliary module
Commissioning
The DIGSY control unit and display starts up in the „ignition on“
position. After a short time, the start-up screen appears. Afterwards,
the control automatically loads the main menu.
Main menu design
In this screen, all important data are presented in overview form:
· Tank display
· Speed display (rpm)
· Clock
· Operating hours
· Operating displays (see 5.2.8)
· Cooling water temperature
· Hydraulic oil temperature
· Status displays
· Powerline setting
· Buttons and Corresponding menu elds
