Mercury Avator 7.5e User Manual

3. Press the menu button to save the setting.
100
%
0
%
km/h
SAVED
76169
NOTE:Setup is complete. The display will revert back to the main screen.
READY
100
%
0
%
mph
READY
76170
Using and Changing Directional Controls
IMPORTANT:Observe the following:
•
Never change the directional control rapidly from reverse to forward
without stopping at neutral to allow the propeller to stop spinning.
This action could cause outboard and component damages.
•
Do not change the directional control into reverse when the forward
motion of the boat is greater than a no wake speed. This action
could cause outboard or component damages.
OPERATION
eng 95 

Mercury Avator 7.5e Specifications

General

Power Source	Electric
Control	Tiller
Mounting	Transom
Operating Voltage	48V
Power	750W
Engine Type	Electric motor
Run Time	Up to 1 hour at full throttle
Propeller	3-blade
Warranty	2 years
Shaft Length	Short
