9. Connect the SmartCraft CONNECT harness connector to the boat
harness.
a - SmartCraft CONNECT
b - Cable tie
c - SmartCraft CONNECT harness
d - 10‑pin connector
10.
Install the starboard cowl panel on the outboard. Refer to Starboard
Cowl Panel Installation.
11.
Install the front lower cowl panel on the outboard. Refer to Front Lower
Cowl Panel Installation.
12.
Install the front upper cowl panel on the outboard. Refer to Front Upper
Cowl Panel Installation.
13.
Install the battery in the outboard. Refer to Battery Installation.
Near Field Chipset (NFC) Decal and Mercury Marine App
The under‑hood label on the Avator 7.5e outboard contains an NFC that can be
read by NFC‑enabled smart devices.
• Android™ devices will link to the the Google Play App Store™ for
downloading the Mercury Marine App.
• iOS™ devices will link to the Apple AppStore™ for downloading the
Mercury Marine App.
• If the Mercury Marine App has already been downloaded, the phone will
be prompted to open the App.
a
b
b
b
c
76061
d
FEATURES AND CONTROLS
 80 eng

Mercury Avator 7.5e Specifications

General

Power Source	Electric
Control	Tiller
Mounting	Transom
Operating Voltage	48V
Power	750W
Engine Type	Electric motor
Run Time	Up to 1 hour at full throttle
Propeller	3-blade
Warranty	2 years
Shaft Length	Short
