Mercury Avator 7.5e User Manual

a - Tiller handle lock release lever
b - Throttle grip friction knob
c - Tiller handle
•
Tiller handle yaw ‑ The tiller handle yaw allows the operator to change
the angle of the handle 12° left or right of center. For storage the tiller
handle can be moved up to 90° left or right of center.
•
Tiller handle yaw release:
a. Push down on the tiller handle yaw release lever.
b. With one hand, hold the outboard to keep it from moving with the
lever.
c. Adjust the position of the tiller handle, right or left.
76103
a
b
c
FEATURES AND CONTROLS
 64 eng

Mercury Avator 7.5e Specifications

General

Power Source	Electric
Control	Tiller
Mounting	Transom
Operating Voltage	48V
Power	750W
Engine Type	Electric motor
Run Time	Up to 1 hour at full throttle
Propeller	3-blade
Warranty	2 years
Shaft Length	Short
