If the resistance is not as indicated, inspect the sensor wiring and connections.
Trim Switches and Sensor ‑ DTS
a - PCM connector A
b - PCM connector B
c - PCM connector C
d - Trim harness connector
e - Trim position sensor connector
f - Cowl tilt switch connector
g - Hot stud (battery +)
Connector Pin Wire Color Function PCM
65763
B
A
C
A Red 12 V battery power (+) –
B Green/white Trim down relay control BM4
C Light blue/white Trim up relay control AA3
65697
4
3
1
2
1 N/A Not used –
2 Black/green Sensor ground C (–) CE3
3 Yellow Trim position sensor signal BC2
4 Purple/black Sensor power C (+) CE4
65695
1
2
3
1 Red 12 V battery power (+) –
2 Green/white Trim down (from switch) CC3
3 Light blue/white Trim up (from switch) CC2
S109B
GRN/WHT
YEL
PPL/BLK
BLK/GRN
LT BLU/WHT
GRN/WHT
RED
LT BLU/WHT
LT BLU/WHT
GRN/WHT
GRN/WHT
RED
RED
YEL
PPL/BLK
BLK/GRN
LT BLU/WHT
3
2
1
H4
C2
C3
E3
E4
A1
C2
M4
A1
A1
A3
H4
2
3
4
1
A
B
C
A
B
C
D
E
F
G
H
1
2
3
4
A
B
C
D
E
F
G
H
A B
C
D E F G H
J
K
AB
C
DEFGH
J
K
1
3
2
4
L
M
L
M
A
B
C
D
E
F
G
H
1
2
3
4
A
B
C
D
E
F
G
H
M
A
4
1
A
H
1
4
H
A
4
1
1 2
3
1
2
3
65916
a
b
c
d
e
f
g
Conventional Midsection (CMS) Power Trim
90-8M0146617 eng JULY 2018 © 2018 Mercury Marine Page 6C-15

Mercury V8 250 Specifications

General

Engine Type	V8
Horsepower	250 HP
Displacement	4.6L
Fuel Induction System	Electronic Fuel Injection (EFI)
Steering	Hydraulic Steering
Gear Ratio	1.75:1
Cylinders	8
Starting	Electric Start
Full Throttle RPM Range	5200-6000 RPM
Alternator Amp	85 amp
Shaft Length	25 in
Weight	527 lbs
Fuel Type	Unleaded 87 octane minimum
