Mercury V8 250 User Manual

Pin Function Wire Color
Application
Notes
Description
CC4
Fuel level 1 sensor
signal
Pink/black –
Circuit is designed to read low resistance sensors, typically
between 0 and 200 ohms. Uses standard fuel tank sending
units.
CD4 Not used – – –
CE4 Sensor power C Purple/black –
Dedicated 5 V positive power supply for transom and hull
sensors. Maintains 5 V regardless of battery voltage
fluctuations.
CF4 Not used – – –
CG4 Driver power 2 Red/blue –
12 V power supply from the battery, through the main power
relay (MPR) and through the PCM 112. The PCM controls
the MPR through pin AA2. This power is used for high
current actuators.
CH4 Shift actuator A (+) Red/purple – –
PCM 112 Important Information and Pinouts
90-8M0146617 eng JULY 2018 © 2018 Mercury Marine Page 2A-11

Mercury V8 250 Specifications

General

Engine Type	V8
Horsepower	250 HP
Displacement	4.6L
Fuel Induction System	Electronic Fuel Injection (EFI)
Steering	Hydraulic Steering
Gear Ratio	1.75:1
Cylinders	8
Starting	Electric Start
Full Throttle RPM Range	5200-6000 RPM
Alternator Amp	85 amp
Shaft Length	25 in
Weight	527 lbs
Fuel Type	Unleaded 87 octane minimum
