Page #97 background image
Fault Failure
PCM Fault Name
Code Description Code Description
3034
Electronic shift control forward
adapt
6
The device, calculation or process detected a
fault.
ESC_NoAdapt_Forward
3037 Electronic shift control timeout 6
The device, calculation or process detected a
fault.
ESC_TimeOut
3039 Reverse gear unavailable 23 A particular state or condition exists. Loss_of_Shift_Command
3049 Hydraulic shift 16
The ECU has detected a problem when trying to
output a signal to this device.
SHFT_OutputFault
3061 Fuel pump 16
The ECU has detected a problem when trying to
output a signal to this device.
FULP_OutputFault
3152 Warning horn 16
The ECU has detected a problem when trying to
output a signal to this device.
HORN_OutputFault
3171 Starter 16
The ECU has detected a problem when trying to
output a signal to this device.
STRT_OutputFault
3181 Trim up 16
The ECU has detected a problem when trying to
output a signal to this device.
TRMU_OutputFault
3182 Trim down 16
The ECU has detected a problem when trying to
output a signal to this device.
TRMD_OutputFault
4001 Demand crosscheck 6
The device, calculation or process detected a
fault.
Demand_XCheck_Diff
4002 Shift crosscheck 6
The device, calculation or process detected a
fault.
Shift_XCheck_Diff
4003 Helm module crosscheck 6
The device, calculation or process detected a
fault.
MicroChi_PWM_ADC
4004 CAN X Doc 01 state of health 6
The device, calculation or process detected a
fault.
RxDoc1_SOH
4005 CAN P Doc 02 state of health 6
The device, calculation or process detected a
fault.
RxDoc2_SOH
4006 CAN P Doc 03 state of health 6
The device, calculation or process detected a
fault.
RxDoc3_SOH
4007 CAN X Doc 07 state of health 6
The device, calculation or process detected a
fault.
RxDoc7_SOH
4008 CAN X Doc 09 state of health 6
The device, calculation or process detected a
fault.
RxDoc9_SOH
4009 CAN X Doc 10 state of health 6
The device, calculation or process detected a
fault.
RxDoc10_SOH
4010 CAN X Doc 11 state of health 6
The device, calculation or process detected a
fault.
RxDoc11_SOH
4011
CAN bus authentication
timeout
23 A particular state or condition exists. AuthTimeout
4012
CAN P and CAN X state of
health
6
The device, calculation or process detected a
fault.
Dual_CAN_SOH_Faults
4013 Watchdog 23 A particular state or condition exists. Watchdog_Active
4014 Watchdog module crosscheck 6
The device, calculation or process detected a
fault.
Crosscheck_Failed
4016
Watchdog crosscheck state of
health
6
The device, calculation or process detected a
fault.
SPI_CrosscheckData_SOH
4501 Security device missing 23 A particular state or condition exists. Security_Device_Missing
4502 Security locked 23 A particular state or condition exists. Security_Locked
4503 Security setup 23 A particular state or condition exists. Security_Setup
4602 Fault blocker system voltage 23 A particular state or condition exists. SysVolt_FaultBlocker
Fault Codes
