Merrychef conneX 12e - Page 104

104
Merrychef conneX
®
service and repair manual
7 Circuit boards and diagrams
Back to contents >
7 CIRCUIT BOARD S AND DIAGRA MS
7.2 Circuit diagrams.
conneX
®
wiring diagram 50Hz 200/230V.
Door switches – LV safety interlock circuit
.
Overheat thermostats – ELV safety circuit.
800W Ovens
F1 F2 F3 F4 F5 F6 F7
13 AMP 13 AMP 20 AMP 20 AMP 20 AMP 20 AMP 3 AMP
(L1) (NEATRAL/L2) (L1) (NEATRAL/L2) (L1) (NEATRAL/L2) (L1)
FUSE RATINGS
N / L2
E / GND
Microwave, Heater & Control
Circuit Filter
Mains Filters—13A, 15/16A single phase
L / L1*
N / L2*
15
04
05
F2
09
10
14
08
F1
F3
11
F4
L / L1
26
06
12
F5
07
13
F6
05
11
N/L2
