Fuses.
The fuse assembly (F1, F2, F3, F4, F5 & F6) is located to the front of the mains filter on
the right-hand side of the oven.
Note: Specific fuse rating and function can be found detailed in the circuit diagrams
(Section 7.2)
F7 Is located next to the SMPS on the magnetron duct.
Convection Fan Safety Relay.
The convection fan safety relay is located next to the DF on the cavity base.
