USB Socket.
The USB socket is located on the front left-hand side of the user
interface and connected directly to the UI loom on the underside of
the IO Board.
Speaker.
The speaker is located on the right of the front
panel, behind the UI, by two M7 hex nuts and
connected directly to the UI loom.
Air Filter Securing Magnet.
The air filter is secured in position by two magnets on the cavity assembly.
