3. Red: Self-Recovery Mode
Self-Recovery mode indicates that the node is powered
on and has successfully booted, but an internet
connection has not been established. This mode should
only occur briefly until the node enters Gateway, Repeater,
or Modem Mode. Occasionally, the device may enter
Self-Recovery mode when transitioning between other
modes - Issue #3.
4. Blue: Gateway Mode
Gateway Mode indicates that the node has successfully
connected to the internet and is acting as the connection
between the mesh network and the internet. This mode
can be achieved by connecting the node to a router via
USB Hub - Issue #7. The ethernet connection must have
unrestricted access to the internet, which should work
with any standard ethernet connection through a router .
If you would like to learn more about the specific
requirements, please visit section 11.c - Common Issues .
5. Green: Repeater Mode
Repeater Mode indicates that the node has successfully
meshed with another online node, thus creating a mesh
network. This mode can only be achieved when a node in
Gateway Mode is present in the mesh and the specific
node is within range of it or another node in Repeater
Mode - Issue #8.
6. Purple: Modem Mode
Modem Mode indicates that the node has been
successfully connected to a cellular network. Similar to
Gateway Mode, it can now serve as a main access point in
a mesh network - Issue #10.
