74 Technical Bulletin—TC-9100 Universal Controller
Item Type MEM R/W Tag Description
Hex Dec
89 137 Number D WP HRI1 High Range AI1
8A 138 Number D WP LRI1 Low Range AI1
8B 139 Number D WP FTC1 Filter Constant AI1
8C 140 Number D WP OFS1 Offset Value AI1
8D 141 1 Byte D WP IOP1 Analog Input 1 Options
X3...X1 not used
X4=0 Input Type: set to 0 (= 0-10V)
X7...X5 Input Mode
=000 Linear Range (0-10V input)
=001 not used
=010 Square Root (0-10V input)
=011 20% zero suppression (2-10V input)
X8 not used
8E 142 Number D WP HRI2 High Range AI2
8F 143 Number D WP LRI2 Low Range AI2
90 144 Number D WP FTC2 Filter Constant AI2
91 145 Number D WP OFS2 Offset Value AI2
92 146 1 Byte D WP IOP2 Analog Input 2 Options (see IOP1)
93 147 Number D WP HRI3 High Range AI3
94 148 Number D WP LRI3 Low Range AI3
95 149 Number D WP FTC3 Filter Constant AI3
96 150 Number D WP OFS3 Offset Value AI3
97 151 1 Byte D WP IOP3 Analog Input 3 Options (see IOP1)
98 152 Number D WP HRI4 High Range AI4
99 153 Number D WP LRI4 Low Range AI4
9A 154 Number D WP FTC4 Filter Constant AI4
9B 155 Number D WP OFS4 Offset Value AI4
9C 156 1 Byte D WP IOP4 Analog Input 4 Options (see IOP1)
9D 157 1 Byte VR R OS TM-9180 Mode Control
X2 X1 Requested Operating Mode
=00 NIGHT Mode
=01 STANDBY Mode
=10 COMFORT Mode
=11 OFF Mode
X3 not used
X4 not used
X5 Alternate Mode Toggle
X6 not used
X7=1 Manual Override
X8=1 TM-9180 Active
9E 158 2 Bytes VR W TIME TM-9180 Clock Synchronization
