Technical Bulletin—TC-9100 Universal Controller 75
Item Type MEM R/W Tag Description
Hex Dec
Summer/Winter Compensation
Module
9F 159 Connection D WP OT@ Outdoor Temperature
A0 160 Number D W SPW Winter Set Point
A1 161 Number D W SPS Summer Set Point
A2 162 Number D W WA Winter Authority Slope
A3 163 Number D W SA Summer Authority Slope
Low Limit Module
A4 164 Connection D WP FT@ Low Limit (Anti-freeze) Temperature
Connection
A5 165 Number D W FSP Low Limit (Anti-freeze) Set Point
A6 166 Number D WP FDIF Low Limit (Anti-freeze) Differential
A7 167 2 Bytes VR R LOO Local Output Override Status
X2 X1 FANS 3-Speed Fan Status
=00 OFF
=01 Speed 1 (Low)
=10 Speed 2 (Medium)
=11 Speed 3 (High)
X3 not used
X4=1 FOS Fan Override by Hardware Input
X6 X5 FANT TM-9180 Fan Override Status
=00 OFF
=01 Speed 1 (Low)
=10 Speed 2 (Medium)
=11 Speed 3 (High)
X7 internal use
X8=1 FOR Fan Override by TM-9180
X9=1 AI01 AI1 Override by TM-9180
X10=1 AI02 AI2 Override by TM-9180
X11=1 AI03 AI3 Override by TM-9180
X12=1 AI04 AI4 Override by TM-9180
X16...X13 not used
