METREL MI 3125 User Manual

MI 3125 InstaltestCOMBO Voltage, frequency, phase sequence
27
Voltage measurement procedure
 Select the VOLTAGE TRMS function using the function selector switch.
 Connect test cable to the instrument.
 Connect test leads to the item to be tested (see figures 5.6 and 5.7).
Measurement runs immediately after selection of VOLTAGE TRMS function.
Figure 5.8: Examples of voltage measurement in three-phase system
Displayed results for single phase system:
Uln...........Voltage between phase and neutral conductors,
Ulpe.........Voltage between phase and protective conductors,
Unpe........Voltage between neutral and protective conductors,
f ...............frequency.
Displayed results for three-phase system:
U12..........Voltage between phases L1 and L2,
U13..........Voltage between phases L1 and L3,
U23..........Voltage between phases L2 and L3,
1.2.3 ........Correct connection – CW rotation sequence,
3.2.1 ........Invalid connection – CCW rotation sequence,
f ...............frequency.

METREL MI 3125 Specifications

General

Type	Multifunction Installation Tester
Insulation Resistance	Yes
Continuity Test	Yes
Loop Impedance	Yes
RCD Testing	Yes
Voltage Measurement	Yes
Frequency Measurement	Yes
Display	LCD
Power Supply	6 x 1.5 V AA batteries
Loop Resistance Resolution	0.01 Ω
Frequency	45 - 65 Hz
Line Voltage Resolution	1 V
Insulation Resistance Test Voltage	50 V, 100 V, 250 V, 500 V, 1000 V
Insulation Resistance Resolution	0.01 MΩ
Continuity Resistance Resolution	0.01 Ω
Test Current	200 mA
DC Voltage	Up to 600 V
Loop Resistance	0.0 Ω - 1999 Ω
Line Voltage	Up to 550 V
Line Voltage Accuracy	±2% ±2 digits
Rated Residual Current	10 mA, 30 mA, 100 mA, 300 mA, 500 mA
Insulation Resistance Range	0.01 MΩ to 1 TΩ
Continuity Resistance	0.0 Ω - 1999 Ω
Dimensions	220 x 103 x 55 mm
Operating Temperature	-10°C to 50°C
Storage Temperature	-20°C to +60°C
Safety Standards	EN 61557
Loop Resistance Accuracy	±(5% + 3 digits)
