MI 3125 EurotestCOMBO Technical specification
54
Nominal voltage range...................... 10 V ÷ 550 V
7.7.4 Online terminal voltage monitor
Measuring range (V) Resolution (V) Accuracy
10 ÷ 550
1
±(2 % of reading + 2 digits)
7.8 General data
Power supply voltage........................ 9 V
DC
(6×1.5 V battery or accu, size AA)
Operation.......................................... typical 20 h
Charger socket input voltage ............ 12 V ± 10 %
Charger socket input current ............ 400 mA max.
Battery charging current ................... 250 mA (internally regulated)
Overvoltage category........................ 600 V CAT III / 300 V CAT IV
Plug commander
overvoltage category ................ 300 V CAT III
Protection classification .................... double insulation
Pollution degree................................ 2
Protection degree ............................. IP 40
Display ............................................ 128x64 dots matrix display with backlight
Dimensions (w × h × d) ..................... 14 cm × 8 cm × 23 cm
Weight ............................................ 1.0 kg, without battery cells
Reference conditions
Reference temperature range........... 10 °C ÷ 30 °C
Reference humidity range................. 40 %RH ÷ 70 %RH
Operation conditions
Working temperature range .............. 0 °C ÷ 40 °C
Maximum relative humidity ............... 95 %RH (0 °C ÷ 40 °C), non-condensing
Storage conditions
Temperature range ........................... -10 °C ÷ +70 °C
Maximum relative humidity ............... 90 %RH (-10 °C ÷ +40 °C)
80 %RH (40
°C ÷ 60 °C)
The error in operating conditions could be at most the error for reference conditions
(specified in the manual for each function) +1 % of measured value + 1 digit, unless
otherwise specified in the manual for particular function.

METREL MI 3125 Specifications

General

Type	Multifunction Installation Tester
Insulation Resistance	Yes
Continuity Test	Yes
Loop Impedance	Yes
RCD Testing	Yes
Voltage Measurement	Yes
Frequency Measurement	Yes
Display	LCD
Power Supply	6 x 1.5 V AA batteries
Loop Resistance Resolution	0.01 Ω
Frequency	45 - 65 Hz
Line Voltage Resolution	1 V
Insulation Resistance Test Voltage	50 V, 100 V, 250 V, 500 V, 1000 V
Insulation Resistance Resolution	0.01 MΩ
Continuity Resistance Resolution	0.01 Ω
Test Current	200 mA
DC Voltage	Up to 600 V
Loop Resistance	0.0 Ω - 1999 Ω
Line Voltage	Up to 550 V
Line Voltage Accuracy	±2% ±2 digits
Rated Residual Current	10 mA, 30 mA, 100 mA, 300 mA, 500 mA
Insulation Resistance Range	0.01 MΩ to 1 TΩ
Continuity Resistance	0.0 Ω - 1999 Ω
Dimensions	220 x 103 x 55 mm
Operating Temperature	-10°C to 50°C
Storage Temperature	-20°C to +60°C
Safety Standards	EN 61557
Loop Resistance Accuracy	±(5% + 3 digits)
