Page #7 background imageLoading...
Page #7 background image
MI 3125 InstaltestCOMBO Warnings and notes
7
Warnings related to measurement functions:
Insulation resistance
Insulation resistance measurement should only be performed on de-energized
objects!
Do not touch the test object during the measurement or before it is fully
discharged! Risk of electric shock!
When an insulation resistance measurement has been performed on a capacitive
object, automatic discharge may not be done immediately! The warning message
and the actual voltage is displayed during discharge until voltage drops below
10 V.
Do not connect test terminals to external voltage higher than 600 V (AC or DC) in
order not to damage the test instrument!
Continuity functions
Continuity measurements should only be performed on de-energized objects!
Parallel impedances or transient currents may influence test results.
Testing PE terminal
If phase voltage is detected on the tested PE terminal, stop all measurements
immediately and ensure the cause of the fault is eliminated before proceeding
with any activity!
SOCKET test
Use Resistance box (A 1195) only for testing with lines disconnected from main
supply!
Notes related to measurement functions:
General
The indicator means that the selected measurement cannot be performed
because of irregular conditions on input terminals.
Insulation resistance, continuity functions can only be performed on de-energized
objects.
PASS / FAIL indication is enabled when limit is set. Apply appropriate limit value
for evaluation of measurement results.
In the case that only two of the three wires are connected to the electrical
installation under test, only voltage indication between these two wires is valid.
Insulation resistance
If voltages of higher than 10 V (AC or DC) is detected between test terminals, the
insulation resistance measurement will not be performed. If voltages of higher
than 10 V (AC or DC) is detected between test terminals, the insulation
resistance measurement will not be performed.
The instrument automatically discharge tested object after finished
measurement.
A double click of TEST key starts a continuous measurement.

Table of Contents

Other manuals for METREL MI 3125

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the METREL MI 3125 and is the answer not in the manual?

METREL MI 3125 Specifications

General IconGeneral
TypeMultifunction Installation Tester
Insulation ResistanceYes
Continuity TestYes
Loop ImpedanceYes
RCD TestingYes
Voltage MeasurementYes
Frequency MeasurementYes
DisplayLCD
Power Supply6 x 1.5 V AA batteries
Loop Resistance Resolution0.01 Ω
Frequency45 - 65 Hz
Line Voltage Resolution1 V
Insulation Resistance Test Voltage50 V, 100 V, 250 V, 500 V, 1000 V
Insulation Resistance Resolution0.01 MΩ
Continuity Resistance Resolution0.01 Ω
Test Current200 mA
DC VoltageUp to 600 V
Loop Resistance0.0 Ω - 1999 Ω
Line VoltageUp to 550 V
Line Voltage Accuracy±2% ±2 digits
Rated Residual Current10 mA, 30 mA, 100 mA, 300 mA, 500 mA
Insulation Resistance Range0.01 MΩ to 1 TΩ
Continuity Resistance0.0 Ω - 1999 Ω
Dimensions220 x 103 x 55 mm
Operating Temperature-10°C to 50°C
Storage Temperature-20°C to +60°C
Safety StandardsEN 61557
Loop Resistance Accuracy±(5% + 3 digits)
