General characteristics
44 Function generator
General characteristics
Environment
Reference temperature 23°C ± 5°C
Operating temperature 0°C to 50°C
Storage temperature -20°C to +70°C
Temperature coefficient < 0.1 x the accuracy by °C
Relative humidity < 80 % RH at 40°C
Sealing IP 20 (EN 60529)
Power
Mains voltage 230 V ± 10 % (115 V ±10 %)
Frequency 50 Hz 60 Hz
Consumption 20 VA max.
Fuse 0,125 A timed (network 230 V)
0,250 A timed (network 115 V)
Removable power cable
Display
LCD custom
Dimensions of visible section 135 x 47.5 mm
Safety
As per IEC 61010-1 (2001) :
Insulation class 1
Degree of pollution 2
Utilisation indoors
Altitude < 2000 m
Protection against input overload voltage: 60 VDC, 40 VAC
Category of power supply overvoltage :
CAT II, 300 V in relation to earth
Category of "FREQ EXT" input overvoltage :
CAT I, 300 V in relation to earth
EMC
This unit was designed in compliance with EMC standards in force and its
compatibility was tested in compliance with the following standards :
Transmission and Immunity : NF EN 61326-1, 1998
Mechanical
characteristics
Casing
Dimensions
Height : 170 mm
Width : 270 mm
Depth : 195 mm
Weight 2.8 kg
Materials ABS VO (self-extinguishing)
Packaging
Dimensions
Height : 308 mm
Width : 338 mm
Depth : 338 mm
