-------ELE£TRICAL
EQUlP~IENT
N
develop
through
lack of
attention
to
the
equipment,
or
damage
to
the
wiring.
The
following pages
set
OUt
the
recommended
procedure
for a systematic
examlna-
tion
to
locate and
remedy
the
causes of
some
of
the
more
usual faults
encountered.
The
sources
of
trouble
are
by no means always
obvious, and in some cases a considerable
amount
of
deduction
from
the
symptoms
is needed before
the
cause is disclosed.
For
instance,
the
engine might not respond to
the
starter
switch:
a hasty inference would be
that
the
starter
motor
is at fault. However, as
the
motor
is
dependent
on
the
battery.
it may be
that
the
battery
is
exhausted.
This. in
turn,
may be due
to
the
dynamo failing
to
charge
the
battery.
and
the
final cause
of
the
trouble
may be, perhaps, a loose
connection
In
some
part
of
the
charging circuit.
If,
after
carrying
out
an examination,
the
cause
of
the
trouble
is
not
found,
the
equipment
should
be checked by
the
nearest
Lucas Service
Depot
or
Agent.
Much needless damage can be done
to
items
of
the
equipment
by
attempting
to
correct
faults
without
the
necessary
equiprnent
and
experience.
THE CHARGING CIRCUIT
r. Battery in low state ofcharge
(a) This
state
will be
shown
by lack of
power
when
starting,
poor
light from
the
lamps,
and
hydrometer
readings below 1·200. It
may be due
to
the
dynamo
not
charging
or
giVing low
or
intermittent
output.
The
ignition warning light will
not
go
out
If
the
dynamo fails
to
charge,
or
will flicker
on and off
ln
the
event
of
intermittent
output.
(b) Examine
the
charging and field circuit
wiring,
tightening
any loose connections
or
renewing
broken
cables. Pay particular
attention
to
the
battery
connections.
(c) Examine
the
dynamo driving
belt;
take
up
any undue slackness by SWinging
the
Fig.
N.]
I.
Should
the
starter
motor
pinion become jammed
with
the
flywheel it may be freed by
rotating
the
spindle
by
the
square
provided on
the
end.
dynamo
outwards
on its
mounting
after
slackening
the
attachment
bolts.
(d)
Check
the
regulator
setting
and
adjust
If
necessary.
(e) If. after carryi ng
out
the
above,
the
trouble
is still
not
cured.
have
the
equipment
examIned by a Lucas Service
Depot
or
Agent.
2. Battery
overcharged
(a) This will be indicated by
burnt-out
bulbs,
ve ry freq u
ent
need for to pping up
the
battery,
and high
hydrometer
readings.
Check
the
charging
current
when
the
engine
Is running steadily with a fully charged
battery
a.nd no lights
or
accessories in
use;
the
charge reading should be
of
the
order
of only
3-4
amperes.
If
the
charge reading Is in excess of
this
value, it is advisable
to
check
the
regulator
setti
ng and adjust if necessary.
N.19
