Program channels
This function supports memory channel
programming.
Memory channels may be programmed
using this function or they may be
downloaded from a PC via an RS232
connection using software available from
www.MGLAvionics.co.za
The V6 provides 99 memory channels for
user programmed frequencies. Each
channel has an associated frequency,
'Name' for the frequency (for example
airport name or code), and 'Type' for the
frequency (for example “ATIS”).
Rotating the VOL/TEST knob moves the
highlight (the line with a dark background) to
select a line for editing.
Channel selected:
Rotate the FREQUENCY knob to select the number of the channel to be
edited.
Frequency selected:
Press the FREQUENCY knob to select between the MHZ or KHZ part of the
frequency setting (the MHz or KHz part will flash to indicate which is
selected).
Rotate the FREQUENCY knob to change the setting.
Name or Type selected:
Press the FREQUENCY knob to cycle through the character positions to edit.
A flashing 'underline' or character indicates the position to be edited. Rotate
the FREQUENCY knob to change the character. Up to six characters are
available.
When finished with editing channels, press the 'MENU' button to return to the
First Level Menu.
Contrast
Factory Default: 40
This function is for adjusting display contrast
as required. A value between 30 and 40 is
suitable for most environments. A lower
value results in a lighter display while a
higher value results in a darker display.
Adjust the contrast so that dark areas are
fully saturated while light areas do not show
any darkening.
14
