For '1+3' and 'Isolate' active, the PILOT microphone is associated with the
PILOT headphones and all three PAX microphones are associated with the
PAX headphones.
For '2+2' and 'Isolate' active, the PILOT and PAX1 microphones are
associated with the PILOT headphones and the PAX2 and PAX3
microphones are associated with the PAX headphones.
Auxiliary input configuration
Factory Default: Off
The two Auxiliary inputs are designated Primary ('P') and Secondary ('S').
They may be configured to be 'ON' or 'OFF' in any combination. Pressing the
FREQUENCY knob cycles through four possible arrangements. Auxiliary
levels are set in the First Level Menu. Screens in the First Level Menu
change according to this setup.
Audio output configuration
Factory Default: IC & RX
An Audio output is provided that can be connected, for example, to a Voice
recorder or an external audio panel. The Receiver ('RX') and the Intercom
('IC') may be connected to this output. Pressing the FREQUENCY knob
cycles through four possible arrangements.
Sidetone configuration
Factory Default: ALL
Sidetone is available from the Transmitter and the Intercom. Pressing the
FREQUENCY knob cycles through three arrangements.
CHANNEL spacing
Factory Default: 25KHz
This allows selection of either 25KHz or 8.33KHz steps for setting operating
frequencies. The 8.33KHz setting allows operation in areas using these
channel allocations. All frequency definitions are in accordance with ICAO
standards (ref ICAO Annex 10 Vol 5 § 4.1.2.4)
RESET
This function allows the Transceiver to be reset to 'Factory Default' settings
as listed for each function above. Memory channels and current active and
standby frequencies are NOT affected by the RESET.
20
