The 'MENU' button
The MENU button allows entry to the two level menu system at any time. The
menus provide access to options and adjustments such as setting intercom,
VOX, and audio levels, and many others.
Menu structure
The V6 Transceiver provides setup options and adjustments on two menu
levels. The First Level Menu is accessed by pressing the “MENU” button. The
Second Level Menu with options that are usually only used during installation,
is accessed via the “Setup” function in the First Level Menu.
VOX/VOGAD adjustments
Squelch adjustment
Edit memory channels
Display contrast adjustment
Microphone level(s) (All or four separate levels according to
configuration)
Music level and mute adjustments
Auxiliary input level(s) – according to configuration
Microphone bandpass filter
Scanning state at power up
Select from channel list(s) (ONLY available if lists are loaded)
Setup - enter Second Level Menu
TX microphone - HOT or VOX/VOGAD
TX lock on RX active
Priority scanning of active frequency
PTT configuration – Join or Separate
Flip-Flop or Direct frequency entry
Microphone level configuration – 1 or 4
Pilot Isolate configuration – 1+3 or 2+2
Auxiliary input configuration
Audio output configuration
Sidetone configuration
25KHz or 8.33KHz channel spacing
RESET to factory defaults
11
SECOND LEVEL MENU
FIRST LEVEL MENU
