P-scan ON / OFF
Factory Default: Onf
Enable or disable Priority scanning. Priority scanning only applies to systems
set for Flip-Flop frequency selection.
With Priority scanning ON and scanning enabled, if reception is on the
standby frequency, there is a brief interruption once every second while the
radio checks the active frequency for a signal. If a strong enough signal is
detected on the active frequency, reception switches to the active channel
unconditionally. Once reception on the active channel ends, reception returns
to the standby frequency or scanning resumes.
PTT Configuration
Factory Default: Join
The V6 Transceiver has two PTT inputs. These may be operated
independently or together. PTT1 is associated with the PILOT microphone
and PTT2 with the PAX1 microphone.
For 'Separate', only the microphone circuit associated with its own PTT is
active during transmission – the other microphone is muted.
For 'Join', both microphone circuits are active during transmit and either PTT
may be used.
Flip-Flop FS / Direct FS
Factory Default: Flip-Flop
Selects either 'Flip-Flop' (active/standby) Frequency Selection or 'Direct'
Frequency Selection.
With Direct Frequency Selection only one frequency is displayed – that of the
active channel. There is no standby channel and scanning is not possible.
MIC Levels
Factory Default: 1
This may be configured for a single level to be used for all microphones or
four levels providing independent control for each of the four microphones.
Microphone level is set in the First Level Menu. Screens in the First Level
Menu change according to this setup.
Pilot Isolate configuration
Factory Default: 1 + 3
Two combinations of microphones with PILOT and PAX headphones are
possible. When the 'Isolate' input is active, microphones are associated with
headphone outputs according to the selected configuration. Receiver audio,
sidetone (during transmit), and Auxiliary inputs are all available to both
headphone outputs.
19
