INSTALLATION
1
Figure 8 Optidew 401 right side panel
Right Side Panel
Number Description
1 SD Card slot
1
2
3
5
4
6
7
Figure 9 Optidew 401 rear panel
Rear Panel
Number Description
1 Sensor Cable connector
2 Temperature probe cable connector
3 Pressure transmitter cable connector
4 Alarm contacts connector
5 RS485 and analog output connector
6 USB port
7 Ethernet port (optional)
