Michell Instruments Optidew User Manual

Optidew User’s Manual
44 97551 Issue 1, February 2018
APPENDIX A
Appendix A Technical Specifi cations
Performance
Dew Point
Measurement
Accuracy
±0.15°C
Reproducibility ±0.05°C
Sensitivity ±0.01°C
Response Stable measurement at +10°C dp within 1 minute
Dew-Point Sensor
Sensor Single Stage Dual Stage Harsh Environment
Dew Point Range
(°C)
-30 to +90 -40 to +90 -40 to +120
Temperature Range
(°C)
-40 to +90 -40 to +90 -40 to +120
% RH Range @
23°C
1.35 to 100 0.45 to 100 0.45 to 100
Mirror Temperature
Measurement
Pt1000, 1/10 DIN Class A
Corrosion &
Saturation
Protection
Active Component Isolation System
Recommended
Sample Flow
Ambient (environmental measurements)
to 2Nl/min (flowing sample)
Pressure 2500 kPag max
Sensor cable
Standard: 90°C max temperature
High temperature: 125°C max temperature
Cable length 0.3, 3, 5, 10 & 20m lengths available
Process connection M36x1.5-6g
Remote PRT
Temperature
Measurement
Accuracy
±0.1°C
Cable length 0.3, 3, 5, 10 & 20m lengths available
Temperature
Measurement
PT100 1/10 DIN Class A
Remote Pressure Sensor (Optional)
Pressure
Measurement
Accuracy
±0.25% FS
Pressure
Measurement
Range
0-160KPa OR 0-2500KPa
Process Connection 1/8” NPT-M
Output 4-20 mA
