MICOM-3F/3T/3R HF-SSB Owner’s Guide
112
MICOM-3R Installation
Figure 13 illustrates the installation procedure for the MICOM-3R.
+
-
F1
30A
Antenna Cable
Green
Red
Black
Vehicle Frame
Ground
12V
Battery
F2
7.5A
Trunk Compartment
Passenger Compartment
Engine
Compartment
Outside the Car
Antenna
Ferrite
Installation
Antenna
Connector
Microphone
Figure 13. MICOM-3R Installation Diagram
Figure 14 shows the location of the installed components within the vehicle.
Radio
ATU
Antenna Cable
DC Power
Cable
BAT
Figure 14. Typical MICOM-3R Installation Within Vehicle
