Micom 3f - To Execute a Bidirectional Handshake with a Net

Using Automatic Link Establishment (ALE)
75
3. To select a different address, use the UP/DOWN keys to scroll to the required address in
the directory, and then press ENTER to confirm your selection.
or
If the station you want to add to the group is not in the
directory:
• Enter the new station using the keypad. If you make a
mistake, scroll to the desired position using <-- (F2)
and/or --> (F3), or clear (CLR (F4)) the whole entry and
start again.
MICOM-3
SAVE
<--
-->
CLR
BIDR
BU_
• When ready, press SAVE (F1) to store the new station in
the directory.
MICOM-3
SEND
PAGE
CHAN
DIR
BUD
I
4. Press PAGE (F2) if you wish to attach a message to the bidirectional handshake process.
After confirming the message, exclamation mark precedes the name of the called station,
indicating that a message has been attached.
5. Press CHAN (F3) if you wish to execute a bidirectional handshake process on a specific
channel.
6. Press SEND (F1) or ENTER in order to initiate the bidirectional handshake process. During
this process, you will see TO alternating with the number of the channel on which the
set up request is being sent.
Note
During the bidirectional handshake process, you can press STOP (F1) or ESC to
abort the entire process.
➤ To execute a bidirectional handshake with a net:
1. Press LQA (F2) to enter the LQA menu.
MICOM-3
BIDR
SOND
LQA
2. Press BIDR (F1).
The last called address is displayed. If this is the net you want,
skip directly to Step 8 below.
MICOM-3
SEND
PAGE
CHAN
BIDR
1001
I
3. Press MORE.
MICOM-3
MULT
BDIR
1001
I
