MICOM-3F/3T/3R HF-SSB Owner’s Guide
20
Note
The CLAR (F1) and NF (F2) function keys are not available for TXO (transmit only)
channels.
• CLIP (F3) – toggles the clipper on/off.
MICOM-3
CLAR
NF
CLIP
NB
CH 1
CLIP - OFF
USB
I
SQ
• NB (F4) – toggles the noise blanker on/off.
MICOM-3
CLAR
NF
CLIP
NB
CH 1
NB - OFF
USB
I
SQ
• ATTN (MORE, F2) – toggles the attenuator on/off.
MICOM-3
ATTN
CH 1
ATTEN - ON
USB
I
SQ
PWR (MORE, F1) – selects the transmit power level (LOW, MED,
HIGH or MAX).
MICOM-3
LOW
MED
HIGH
MAX
CH 1
POWER LOW
USB
SQ
MODE (MORE, F2) – selects the operation mode (SSB, AME or
PLT).
MICOM-3
SSB
AME
PLT
CH 1
MODE SSB
USB
SQ
AGC (MORE, F3) – controls the automatic gain control function
(fast/slow/off).
MICOM-3
CH 1
AGC FAST
USB
SQ
PWR
MODE
AGC
BW
I
BW (MORE, F4) – selects the filter bandwidth.
MICOM-3
CH 1
BW 2.7
USB
SQ
2.1
2.7
3.0
3.3
I
RCLV (MORE, MORE, F1) – displays the receive level when F1 is
pressed.
When ALE is active, three additional options appear:
• CALL – initiates an ALE call.
• PAGE – displays the stacked received messages.
• MON – enables/disables the speaker during ALE link establishment.
For a description of these options, refer to the Using Automatic Link Establishment (ALE) chapter
starting on page 34.
