IP9xx Series
6.0 Configuration
Zone
No.
Restrict From
Start (MHz)
Restrict To
End (MHz)
Restrict From
Start (MHz)
Restrict to
End (MHz)
1 923.200 927.600
2 902.400 902.800 924.000 927.600
3 902.400 903.600 924.800 927.600
4 902.400 904.400 925.600 927.600
5 902.400 905.200 926.400 927.600
6 902.400 906.000 927.200 927.600
7 902.400 906.800
8 912.800 917.200
Table 6A: Restricted Bands for UA1 at 345kbps Link Rate
Table 6B: Restricted Bands for UA1 at 1.1Mbps Link Rate
Zone
No.
Restrict From
Start (MHz)
Restrict To
End (MHz)
Restrict From
Start (MHz)
Restrict to
End (MHz)
1 909.750 926.250
2 902.400 905.250 912.750 926.250
3 902.400 908.250 915.750 926.250
4 902.400 911.250 918.750 926.250
5 902.400 914.250 921.750 926.250
6 902.400 917.250 924.750 926.250
7 902.400 920.250
8 906.750 923.250
None
Zone 1, 2, 3, 4, 5, 6, 7, and 8
Values
Zone Restriction (continued)
