MicroPace StimLab - EPS320 B;BT Configuration

USER INSTRUCTION MANUAL
Page 14 of 49 ENGLISH
6
6 EPS320B/BT CONFIGURATION
6.1 Description of system
The Micropace EPS320B/BT EP Stimulator System is a computerized Cardiac EP diagnostic
stimulator system.
Figure 2 EPS320BT System Components
6.2 System Components
This configuration includes a Bona Computech Light System PC, a separate NEC LCD Display Screen
and a 110-240VAC Mains isolation transformer with the EPS320 system. Appropriate mains cables
are included for proper system installation, as per Packing list below.
LCD Display, MP3076
or MP3114(Touch)
Stimulus
Connection Box,
MP3014 (2Ch) or
MP3086 (4Ch)
Computer,
MP3093
Isolation
Transformer,
e.g. MP3107
Stimulus Generator Unit
(SGU), MP3008
Keyboard,
MP3016
