CARDIAC STIMULATOR
ENGLISH Page 43 of 49
+------- EPS320 Ver:4.0 USER - Configuration Protocol: Pace -------+
¦ ¦
¦ >>PGDN/Enter->Service Page --- --³ 21 Min.auto Sx for RSync_Sx : ms¦
¦ 1 Minimum S1 for PACE : ms³ 22 Tachy Detect Interval : ms¦
¦ 2 Absolute Min S1,eg BURST: ms³ 23 His-coincident RSynced_Sx: ms¦
¦ 3 Minimum Sx (S2-S7) : ms³ 24 : ¦
¦ 4 Min.auto S1 for ATP : ms³ 25 Temp Prot.Boosted Current: - ¦
¦ 5 Min.auto S1 WENCKE/SNRT : ms³ 26 ECG gain Atrial Chan : - ¦
¦ 6 Min.auto S1 for BURST : ms³ 27 ECG gain Ventric Chan : - ¦
¦ 7 Burst -> Overdrive Burst: - ³ 28 ECG gain Ext1 : - ¦
¦ 8 Sound Output Source : - ³ 29 ECG gain Ext2 : - ¦
¦ 9 F9 %RR Percentage : - ³ 30 Soft QRS Detect Setup : - ¦
¦10 Sync1out on(Train+1-n)S1: - ³ 31 QRS Blanking Time-HWare : ms¦
¦11 Decr/Incr N'ERP by Table: - ³ 32 QRS Sync Timeout : ms¦
¦12 W'ke/Brst Autodec'Period: ms³ 33 : ¦
¦13 SNRT Auto Stop : ³ 34 No of Hints ( 13,0=off) : - ¦
¦14 SNRT Duration : s ³ 35 : ¦
¦15 Repeats Multi_Sx Extra's: - ³ 36 Idle Safety Timeout : s¦
¦16 En Wencke Log Decremt'n : - ³ 37 Sense Sound : ms¦
¦17 En Wencke Beat Decrement: - ³ 38 Pace Sound Duration : ms¦
¦18 Rate-adaptive Burst S1 : % ³ 39 Default Setup No.(1-8) : - ¦
¦19 ATP Intraburst Decrement: - ³ 40 Set Global FACTORY PRESET: - ¦
¦20 Touch Scrolling of Menu : ³ 41 Initial Input Method : - ¦
+-----------------------------------------------------------------------------+
1. Minimum S1 for Pace ........... - Minimum allowed S1 value during non-burst, e.g. Pace protocols.
2. Absolute Min S1,eg Burst ..... - Minimum allowed S1 value during Burst, Overdrive Pace, ATP protocols.
3. Minimum Sx (S2-S7) ............ - Minimum allowed S2 to S7 value.
4. Min.auto S1 for ATP ........ - Min. allowed S1 value reached by auto-decrementation in ATP Protocol.
5. Min.auto S1 WENCKE/SNRT - Min. allowed S1 value reached by auto-decrementation in Wenckebach & SNRT Prot.
6. Min.auto S1 for Burst ............ - Min. allowed S1 value reached by auto-decrementation in Burst protocol.
7. Burst -> Overdrive Burst……- Redirect Burst protocol to Overdrive protocol 0= No 1= redirection
8. Sound Output Source ........... - Sound source; 0=none, 1=PC speaker only, 2=External speaker, 3=Both
9. F9 %RR Percentage ............. - Sets F9 – S1 = %RR percentage; range 50% to 99%.
10. Sync1out (Train+1-n)S1 ..... - Send Sync pulse on (drive train+1-value) for triggering recorder, (1=last train pulse).
11. Decr/Incr N'ERP by Table ... - Decr/Increment in Nodal_ERP is from Table of values – use INS on parameter
12. W'ke/Brst autodec’Period ... - Interval between auto-decrementation of S1 in Wencke and Burst Pace protocols.
13. SNRT Auto Stop ................ - Pacing stops at end of SNRT timer expiry.
14. SNRT Duration ................... - Time to alarm in each SNRT pacing train.
15. Repeats MULTI_SX Extra's - Repeat VT extra's before decrementing. NB value 2 => 3 repeated trains.
16. En Wencke log Decremt’n .. - S1 is Auto decremented logarithmically during Wenckebach, i.e. in diminishing steps.
17. En Wencke Beat Decrement - Wenckebach auto-decrementation occurs on every 'TRAIN' no. of stimuli, not time.
18. Rate-adaptive Burst S1 ...... - Initial S1 in Burst & Overdrive protocol will be thus % of RR interval; 0=disabled.
19. ATP Intraburst Decrement .. - Intra-burst reduction in S1 value, i.e. scanning.
20. Touch Scrolling of Menus ... - Allows sliding of finger on menus..
21. Min.auto Sx for RSync_Sx .. - Minimum automatically decremented Sx value for RSynced_SX protocol.
22. Tachy Detect Interval ...... - Sets default tachycardia detect interval for StopOnTachy Pause mode.
23. His-coincident RSynced_Sx - Sets nominal HV interval for calculating His-coincident S2 (RR-HV).
24.
25. Temp Prot.Boosted Current - Pacing current is boosted by this amount (as mA or %).
26. ECG gain Atrial Chan ......... - Gain for Atrial catheter tip ECG, 1= smallest gain, 4=largest.
27. ECG gain Ventric Chan ..... - Gain for Ventricular catheter tip ECG, 1= smallest gain, 4=largest.
28. ECG gain Ext1 .................... - Gain for External amplified ECG, 1= smallest gain, 2=largest.
29. ECG gain Ext2 .................... - Gain for External amplified ECG, 1= smallest gain, 2=largest.
30. Soft QRS Detect Setup ... - Default setup for QRS Detect Menu.
31. QRS Blanking Time-HWare - Minimum Hardware RR detector blanking time – used only if Var 30 is ‘0’.
32. QRS Sync timeout .............. - If no QRS detected by time out, pacing triggered anyway.
33.
34. No of Hints (14,0=off) ....... - Number of Hints on program launch, 0= disable.
35.
36. Idle safety timeout .............. - Idle keyboard for this time triggers safety standby requiring pressing ESC to cont.
37. Sense sound ...................... - Duration of sound made with each QRS sense. (surrogate for loudness).
38. Pace sound Duration .......... - Duration of sound made with each stimulus by PC and SGU (surrogate for loudness).
39. Default Setup No.(1-5) ...... - Setup loaded on program launch.
40. Set Global Factory Preset... - Resets all program parameters to Factory presets.
41. Initial Input Method ............ - Input device; 1=Both, 2= Touch screen only, 3= Keyboard only.
Note: Press 'h' to obtain further, more detailed help for any variable under the cursor.
Table 8 Configuration Menu Page
